Product Features:
• Forged alloy heat treated hook.
• Forged steel swivel tees and yokes .
• Hook from H418 and shackle assemblies from H419 on 4-1/2” through 14” sizes can be interchanged.
• Can be furnished with bronze bushings or roller bearings.
• Opening feature permits insertion of rope while block is suspended from gin-pole.
• 3” thru 18” 418 blocks have exclusive bolt-retaining spring to assure no lost bolts.
• Pressure lube fittings.
• 3” - 10” feature dual rated Wireline sheaves.
• Fatigue rated.
• Ultimate Load is 4 times the Working Load Limit.
Safety & Maintenance Notes:
• Before each use, carefully inspect the snatch block. If any deformation, cracks, or signs of damage are
detected, discontinue use immediately and replace with a new unit.
• Regularly use the grease fitting to maintain smooth operation and extend the service life of the product.
• Always follow proper winching and recovery procedures, including the use of appropriate safety equipment
and adhering to the rated load limits.
